Blueprint packages

Blueprint packages
(Includes 8 sets of drawings)

Site Plan

an outline of the foundation of your home on a standard retangular lot with front, rear, and side yards shown ( dimensions are left blank to be completed by the owner or builder)
grading calculatons are also left blank, to be completed by owner or builder. Your local building authority may require a site plan drawn accurately showing your house in relation to your actual lot. We can supply you with a custom site plan with all necessary dimensions and calculations for a nominal fee.

Foundation Plan

all necessary structural details
exterior and interior dimensions

Floor Plans

all necessary structural details
exterior and interior dimensions
door, closet, and window locations
plumbing fixture locations

Exterior Elevations

exterior view of all four sides of the house
window and door locations
exterior finishes (ie siding, brick or stone, stucco, trim detail, roofing)

Cross Sections and Details

all details to reasonably explain the overall construction of the house

If you require a different foundation plan than shown , this can be done for a nominal charge.
